Name: Welding positioners type SPK-D
Brand: KOVACO
SKU: SPK-D

SPK-D

Bearing capacity from 2,400kg to 30t

A fully covered double column two-axis positioner for long parts. The hydraulic lift significantly speeds up height adjustment compared to screw positioners. Even the basic configuration positioner features stepless adjustment of table rotation speed in the entire range and is equipped with a START-STOP system. Various optional features of the control system further expand the control capabilities of the positioner. Even the basic configuration positioner features a system for axis measurement and a position programming option with a quick position selection on the touch screen.

Fully covered
Double column double-axis positioner for long parts
Hydraulic lift
Stepless table speed control with START-STOP
Anchoring required
Optional remote control
Optional foot switch for START-STOP
Optional customization of the clamping table to customer specification

Request a quote Back to welding positioners

Specifications

Technical parameters.

Type	SPK 12-D	SPK 25-D	SPK 50-D	SPK 100-D	SPK 150-D
Bearing Capacity (kg)	2,400	5,000	10,000	20,000	30,000
Table Torque (Nm)	9,220	21,180	61,184	106,500	283,000
Table Rotation Speed (rpm)	0.06 - 0.7	0.1 – 1.2	0.08 – 1.0	0.06 – 0.8	0.03 – 0.4
Lifting Speed (m/min)	1.6	1.6	1.6	1.2	1.1
A (mm)	1,280	1,500	1,600	2,200	2,400
B (mm)	1,200	1,270	2,000	1,900	1,900
C (mm)	2,640	3,090	3,460	4,310	4,950
D (mm)	800	850	900	1,100	1,250
DS (mm)	1,500 – 5,000	2,000 – 8,000	2,000 – 12,000	2,000 – 22,000	3,000 – 30,000
P (mm)	1,735	1,935	2,160	2,880	3,285
Z (mm)	1,000	1,100	1,200	1,800	2,000
Hmin (mm)	735	835	960	1,080	1,285
Weight (kg)	3,450	5,350	11,750	19,340	26,660

Type	SPK 12-D	SPK 25-D	SPK 50-D	SPK 100-D	SPK 150-D
Load Capacity (lb)	5,291	11,023	22,046	44,092	66,139
Table Turning Torque (ft-lb)	6,800	15,622	45,127	78,550	208,730
Table Turning Speed (rpm)	0.06 - 0.7	0.1 – 1.2	0.08 – 1.0	0.06 – 0.8	0.03 – 0.4
Lifting Speed (ft/min)	0.06	0.06	0.06	0.05	0.04
A (in)	50.4	59.1	63.0	86.6	94.5
B (in)	47.2	50.0	78.7	74.8	74.8
C (in)	104.0	121.7	136.2	169.7	194.9
D (in)	31.5	33.5	35.4	43.3	49.2
DS (in)	59.1 – 196.9	78.7 – 315.0	78.7 – 472.4	78.7 – 866.1	118.1 – 1,181
P (in)	68.3	76.2	85.0	113.4	129.3
Z (in)	39.4	43.3	47.2	70.9	78.7
Hmin (in)	28.9	32.9	37.8	42.5	50.6
Weight (lb)	7,606	11,795	25,904	42,637	58,775

Welding positioners type SPK-D

Technical parameters.

Machine dimensions.
