Name: Welding positioners type SP
Brand: KOVACO
SKU: SP

Bearing capacity from 600kg to 15t

A three-axis positioner without anchoring requirement allows independent position adjustments in three axes. In comparison with the screw positioners, the hydraulic arm lift significantly speeds up the height adjustment. The positioner, even in its basic configuration, features stepless adjustment of table rotation speed in its entire range and is equipped with a START-STOP system. Various optional features of the control system further expand the control capabilities of the positioner. In addition to manual operation, the positioner can be equipped with a position programming system.

No anchoring required
Hydraulic arm lift
Option to change the arm position and thus the centre of gravity of the weldment
Stepless arm rotation speed control
Stepless table speed control with START-STOP
Optional remote control
Optional foot switch for START-STOP
Optional position programming
Optional customization of the clamping table to customer specification
Optional arm extension
Optional lift increase

Request a quote Back to welding positioners

Specifications

Technical parameters.

Type	SP 6	SP 12	SP 25	SP 50	SP 100	SP 150
Bearing Capacity (kg)	600	1,200	2,500	5,000	10,000	15,000
Arm Torque (Nm)	1,460	4,610	10,590	24,150	53,250	141,500
Table Torque (Nm)	1,250	2,530	4,780	8,300	29,380	41,730
Arm Rotation Speed (rpm)	0.1 – 1.5	0.06 – 0.8	0.07 – 0.9	0.04 – 0.6	0.04 – 0.5	0.03 – 0.4
Table Rotation Speed (rpm)	0.1 – 1.7	0.1 – 1.1	0.07 – 1.1	0.09 – 1.3	0.05 – 0.7	0.05 – 0.7
Lifting Speed (m/min)	0.7	1.2	1.3	1.1	1.0	0.9
A (mm)	2,590	2,850	3,300	3,800	4,900	5,330
B (mm)	1,550	1,600	1,700	2,000	2,330	2,400
C (mm)	1,690	2,320	2,560	3,040	3,590	3,600
D (mm)	700	800	850	900	1,100	1,250
P (mm)	1,336	1,525	1,715	2,061	2,606	2,700
R (mm)	1,000	1,200	1,550	1,800	2,500	2,600
Z (mm)	600	1,000	1,100	1,200	1,350	1,350
Hmin (mm)	500	450	460	650	830	1,020
Weight (kg)	1,450	2,360	3,850	7,150	14,850	23,200

Type	SP 6	SP 12	SP 25	SP 50	SP 100	SP 150
Bearing Capacity (lb)	1,323	2,646	5,512	11,023	22,046	33,069
Arm Torque (lb-ft)	1,077	3,400	7,811	17,812	39,275	104,365
Table Torque (lb-ft)	922	1,866	3,526	6,122	21,670	30,778
Arm Rotation Speed (rpm)	0.1 – 1.5	0.06 – 0.8	0.07 – 0.9	0.04 – 0.6	0.04 – 0.5	0.03 – 0.4
Table Rotation Speed (rpm)	0.1 – 1.7	0.1 – 1.1	0.07 – 1.1	0.09 – 1.3	0.05 – 0.7	0.05 – 0.7
Lifting Speed (ft/min)	2.3	3.9	4.3	3.6	3.3	3.0
A (in)	102.0	112.2	129.9	149.6	192.9	209.8
B (in)	61.0	63.0	66.9	78.7	91.7	94.5
C (in)	66.5	91.3	100.8	119.7	141.3	141.7
D (in)	27.6	31.5	33.5	35.4	43.3	49.2
P (in)	52.6	60.0	67.5	81.1	102.6	106.3
R (in)	39.4	47.2	61.0	70.9	98.4	102.4
Z (in)	23.6	39.4	43.3	47.2	53.1	53.1
H1min (in)	19.7	17.7	18.1	25.6	32.7	40.2
Weight (lb)	3,197	5,203	8,488	15,763	32,737	51,148

Welding positioners type SP

Technical parameters.

Machine dimensions.
