Name: Welding positioners type SP-DL
Brand: KOVACO
SKU: SP-DL

SP-DL

Bearing capacity from 2,400kg to 20t

A double column two-axis positioner for long parts. The hydraulic lift significantly speeds up height adjustments compared to screw positioners. The positioner, even in its basic configuration, allows stepless adjustment of table rotation speed in its entire range and is equipped with a START-STOP system. Various optional features of the control system further expand the control capabilities of the positioner. Even the basic configuration positioner features a position programming system with a quick position selection on the touch screen.

A double column positioner for long parts
Hydraulic lift
Stepless table speed control with START-STOP
Anchoring required
Optional remote control
Optional foot switch for START-STOP
Optional customization of the clamping table to customer specification

Request a quote Back to welding positioners

Specifications

Technical parameters.

Type	SP 12-DL	SP 25-DL	SP 50-DL	SP 100-DL
Bearing Capacity (kg)	2,400	5,000	10,000	20,000
Table Torque (Nm)	13,613	20,407	37,630	74,754
Lifting Speed (m/min)	1.56	1.56	1.56	1.50
Table Rotation Speed (rpm)	0.073 – 0.95	0.074 – 0.96	0.078 – 1.02	0.075 – 0.98
A (mm)	1,350	1,415	1,570	1,700
B (mm)	1,030	1,070	1,260	1,500
C (mm)	2,620	3,080	3,450	3,680
D (mm)	700	800	1,000	1,150
DS (mm)	1,500 – 5,000	2,000 – 8,000	2,000 – 12,000	2,000 – 22,000
P (mm)	1,830	2,200	2,450	2,625
Z (mm)	1,200	1,500	1,700	1,800
Hmin (mm)	630	700	750	825

Type	SP 12-DL	SP 25-DL	SP 50-DL	SP 100-DL
Bearing Capacity (lb)	5,291	11,023	22,046	44,092
Table Torque (lb-ft)	10,040	15,051	27,754	55,136
Lifting Speed (ft/min)	5.1	5.1	5.1	4.9
Table Rotation Speed (rpm)	0.073 – 0.95	0.074 – 0.96	0.078 – 1.02	0.075 – 0.98
A (in)	53.1	55.7	61.8	66.9
B (in)	40.6	42.1	49.6	59.1
C (in)	103.1	121.3	135.8	144.9
D (in)	27.6	31.5	39.4	45.3
DS (in)	59.1 – 196.9	78.7 – 314.9	78.7 – 472.4	78.7 – 866.1
P (in)	72.0	86.6	96.5	103.3
Z (in)	47.2	59.1	66.9	70.9
Hmin (in)	24.8	27.6	29.5	32.5

Welding positioners type SP-DL

Technical parameters.

Machine dimensions.
